✅ Heavy‑duty steel frame for stable, non‑deforming long‑time operation
✅ One‑pass coarse grinding, fine grinding & polishing
✅ Adjustable bevel angle 2°‑30°, max bevel width up to 40 mm
✅ Frequency‑conversion stepless feeding‑speed regulation, simple operation
‑ Advanced PLC control ensures accurate bevel‑angle and dimension repeatability, lowering reject rate in mass‑production.
‑ Robust heavy‑welded steel main frame, effectively avoids structural deformation even under long‑time continuous workshop operation.
‑ Completes coarse grinding, fine grinding and polishing within one feeding pass, greatly improving production throughput.
‑ Front pressure plate adopts lifting adjustment system, easy adaption for glass pieces of different dimensions.
‑ Thickened‑steel pressure plates reinforce the conveyor assembly, achieving stable glass transmission and higher processing accuracy.
‑ Frequency‑conversion motor with stepless transmission mechanism; feeding speed can be freely adjusted according to glass material and required finish quality.
| TECHNICAL SPECIFICATIONS | |
| voltage | Power |
| 380v/50Hz | 21.5kw |
| Bevel angle | Max bevel width |
| 2°-30° | 40mm |
| Glass thickness | Feeding speed |
| 3- 19mm | 0.5-5m/min |
| Min size | Weight of machine |
| 30x30mm | 4000kg |
| Overall size(LxWxH) | Machine over size |
| 6800x1300x2500mm | 3600x1200x1800mm |
‑ Consumable spare‑parts supply: diamond grinding wheels, polishing wheels, pressure‑plate components, conveyor parts, PLC control accessories.
‑ Complete operation manual and parameter‑setting video for installation & commissioning.
‑ Online technical support for troubleshooting and daily maintenance guidance.
‑ Optional configuration upgrade available upon customer request.
